雞肉粒料理包包裝機

RL - GD - ZK160/200 l type automatic food packaging machine
This equipment is mainly composed of give bag packaging machine, conveyor JiLiangCheng or bowl, soup of the filler, applicable to the fast food industry, food industry. Food packages, such as beef noodles food packages, and other quantitative packaging materials operations.

1. Packing speed, stable performance. Make the enterprise implements the packaging automation, so as to improve the production efficiency, greatly reduced the cost of production.
2. The man-machine interface (PLC + HMI) control system, realize the mechanical and electrical integration, easy operation and simple.
3. Adjust the bag width with motor control, hold down the control button one-time organic clip width adjustment, easy to operate, save time and effort.
4. Using high quality components, to ensure the lasting stability of the machine.
5. Packaging material consumption is low, the machine is used bag, packaging design is exquisite, the sealing of good quality and to improve the grade of the product.

Type of RL - GD - ZK160L RL - GD - ZK200L
PP/PE bag material composite membrane
Bag type flat bags, cooking bags, aluminum foil bag, PE bag, compound bag, etc
W bag size: 80-160 - mm L: 80-210 - mm W: 130-200 - mm L: 300 mm or less
Fill the range of 10-500 - g
Accuracy of + / - 1% or less
Packing speed is 30 to 60 bags/min (speed is determined by the material itself and the filling weight)
Voltage 380 v three-phase 50 hz
8 kw power
The compressed air is 0.6 m3 / min (provided by the user)
Cooling water cooling water: 15-20 ° C, 3 litres/minute
